Planer

Brokk planers remove concrete, paint, asbestos, or other layers in a controlled manner up to a certain depth

General info about Planer

Additional tools significantly enhance your demolition robot's efficiency and versatility. Explore our extensive and continually growing range of original Brokk attachments and demolition tools designed to support and advance your business.

*Available with cover and suction
**Extra pressure level needed
***Requires extra hydraulic function, drainage hose, CAN cable, counterweight in some occations
Requires load holding. On request
****Requires drainage hose
All weights refer to attachments incl. mounting kit

PRODUCT SHEET – bcp215, bcp250, bcp350

PRODUCT SHEET – ex20hd, ex30hd

Technical Specifications

	Cutting depth	Stroke length	Cutting width	Weight	Made for
BCP 215* *	0-5 mm/0-0.2 in	1300 mm/51.2 in	265 mm/10.4 in	265 kg/584 lbs	Brokk 120D, 130⁺
BCP 250* ***	0-5 mm/0-0.2 in	1530 mm/60.2 in	265 mm/10.4 in	350 kg/771 lbs	Brokk 200⁺
BCP 350* ***	0-5 mm/0-0.2 in	1400 mm/55.1 in	335 mm/13.2 in	570 kg/1256 lbs	Brokk 300⁺, 500⁺, 520D
EX20HD* ****	0-70 mm/0-2.8 in	-	200 mm/7.9 in	210 kg/463 lbs	Brokk 170⁺, 200⁺
EX30HD* ****	0-120 mm/0-4.7 in	-	300 mm/11.8 in	460 kg/1014 lbs	Brokk 300⁺, 500⁺, 520D
